| Brand Name: | ZHENGYUAN |
| Model Number: | SL1300S |
| MOQ: | 1 set |
| Price: | $145000 |
| Payment Terms: | tt,L/C,T/T,Western Union,MoneyGram |
| Supply Ability: | 25 sets / month |
The Crawler Water Well Drilling Rig is a powerful and versatile machine designed to efficiently drill water wells in various terrains. Equipped with advanced features and robust construction, this rig offers exceptional performance and reliability for water well drilling projects.
One of the key highlights of the Crawler Water Well Drilling Rig is its impressive Jacks Stroke of 1.7m. This extended stroke length allows the rig to effectively penetrate through different soil layers, ensuring precise and deep drilling results. Whether working in soft or hard soil conditions, the rig's jacks stroke ensures stable and accurate drilling operations.
Efficiency is further enhanced by the rig's Traveling Speed of 6km/h. With the ability to move swiftly between drilling locations, the Crawler Water Well Drilling Rig maximizes productivity and minimizes downtime. This fast traveling speed enables operators to quickly reposition the rig, saving valuable time during water well drilling projects.
The Crawler Water Well Drilling Rig is also equipped with a powerful Max Rotary Torque ranging from 15000 to 30000Nm. This high torque output allows the rig to tackle challenging drilling tasks with ease, providing the necessary force to overcome resistance and achieve optimal drilling depths. Whether drilling through rock formations or dense soil, the rig's impressive rotary torque ensures efficient and effective performance.
When it comes to hydraulic capabilities, the rig offers a versatile Working Pressure range of 1.65 to 8Mpa. This adjustable working pressure allows operators to adapt the rig's performance based on the specific requirements of each drilling project. Whether fine-tuning the pressure for different geological conditions or optimizing efficiency for varying depths, the rig's flexible working pressure ensures precise and tailored drilling operations.
Furthermore, the Crawler Water Well Drilling Rig features a Rotate Speed ranging from 86 to 170r/min. This variable rotate speed allows operators to control the drilling process with precision, adjusting the rotational speed to suit different soil types and drilling conditions. The ability to fine-tune the rotate speed ensures smooth and efficient drilling operations, resulting in high-quality water wells.
In conclusion, the Crawler Water Well Drilling Rig stands out as a reliable and high-performance machine that excels in water well drilling applications. With its impressive Jacks Stroke, Traveling Speed, Max Rotary Torque, Working Pressure, and Rotate Speed, this rig offers exceptional capabilities for a wide range of drilling projects. Whether drilling in challenging terrains or varying soil conditions, the Crawler Water Well Drilling Rig delivers consistent and efficient performance, making it a valuable asset for water well drilling contractors and professionals.
| Technical parameters | Unit |
SL1300S |
| Max drilling depth | M | 1300 |
| Drilling diameter | mm | 105-900 |
| Air pressure | Mpa | 1.65-8 |
| Air consumption | m³/min | 16-120 |
| Drill pipe length | m | 13 |
| Drill pipe diameter | mm | 114/127 |
| Axial pressure | T | 10 |
| Lifting force | T | 60 |
| Fast lifting speed | m/min | 29 |
| Fast feeding speed | m/min | 51 |
Max rotary torque |
Nm | 24000/ 12000 |
| Max rotary speed | r/min | 85/170 |
| Big auxiliary winch lifting force | T | 5 |
| Small auxiliary winch lifting force | T | 2.5 |
| Jacks stroke | m | 1.7 |
| Drilling efficiency | m/h | 10-35 |
| Moving speed | Km/h | 6 |
| Uphill angle | 21° | |
| Weight of the rig | T | 25 |
| Dimension | m | 10.85*2.25*2.98 |
Engine |
/ | Weichai 220KW |
| Working condition | Unconsolidated formation and stone head | |
| Drilling method | Top drive hydraulic rotary and pushing hammer or mud drilling | |
| Matched DTH hammer | Medium and high air pressure series | |
| Optional accessories | Mud pump,Centrifugal pump,Generator,foam pump | |
The Crawler Water Well Drilling Rig offered by Shandong Zhengyuan (Model: SL1300S) is a versatile and reliable drilling equipment suitable for various applications and scenarios.
Product Application Occasions and Scenarios:
1. Water Well Construction: The Crawler Water Well Drilling Rig is ideal for drilling water wells in different terrains and geologies, providing access to clean and potable water sources even in remote locations.
2. Geological Exploration: With a rotate speed of 86-170r/min and a max rotary torque of 15000-30000Nm, this rig is well-suited for geological surveying and exploration activities, helping to collect valuable data for various industries.
3. Construction Projects: The Crawler Water Well Drilling Rig can be used in construction projects requiring foundation piling, such as building construction, bridge construction, and infrastructure development.
4. Mineral Exploration: Its power of 264kw and weight of 25T make it suitable for mineral exploration tasks, enabling efficient and precise drilling operations in search of valuable mineral deposits.
Key Product Details:
- Place Of Origin: Shandong Province, China
- Certification: ISO
- Minimum Order Quantity: 1 SET
- Price: $45000
- Packaging Details: According to customer requirements
- Delivery Time: 20 days
- Payment Terms: 30% TT for deposit
- Supply Ability: 30 SETS per month
- Rotate Speed: 86-170r/min
- Max Rotary Torque: 15000-30000Nm
- Power: 264kw
- Weight: 25T
- Drill Rod Length: ≤6m
The Crawler Water Well Drilling Rig product offers comprehensive technical support and services to ensure optimal performance and customer satisfaction. Our dedicated team of experts is available to assist with any product-related inquiries, troubleshooting, and maintenance needs.
Our services include installation guidance, training programs, spare parts supply, and on-site support to address any issues that may arise during operation. We are committed to delivering reliable and efficient solutions to meet the needs of our customers and maximize the performance of the drilling rig.
A: The brand name of this water well drilling rig is Shandong Zhengyuan.
Q: Where is the place of origin for the Crawler Water Well Drilling Rig?
A: The place of origin for this rig is Shandong Province, China.
Q: What is the certification of this Crawler Water Well Drilling Rig?
A: This rig is certified with ISO.
Q: What is the minimum order quantity for purchasing this rig?
A: The minimum order quantity for this water well drilling rig is 1 set.
Q: What is the price of the Crawler Water Well Drilling Rig?
A: The price of this rig is $45,000.
Q: How are the packaging details for this water well drilling rig?
A: The packaging details are according to the customer's requirements.
Q: What is the delivery time for the Crawler Water Well Drilling Rig?
A: The delivery time for this rig is 20 days.
Q: What are the payment terms for purchasing this water well drilling rig?
A: The payment terms are 30% TT for deposit.
Q: What is the supply ability of the Crawler Water Well Drilling Rig?
A: The supply ability is 30 sets per month.
