| Brand Name: | Shandong Zhengyuan |
| Model Number: | FSL600 |
The Reverse Circulation Drilling Rig is a highly efficient and robust Geological Drilling Rig Machine designed to meet the demanding requirements of modern geological exploration and mining operations. With its compact dimensions of 7 meters in length, 2.1 meters in width, and 2.9 meters in height, this rig is engineered to provide exceptional performance while maintaining excellent maneuverability and ease of transport. Its size makes it suitable for a variety of terrains and working conditions, ensuring that it can be deployed quickly and efficiently in diverse geological environments.
One of the standout features of this Geological Drilling Rig Machine is its impressive axial pressure capacity of 7 tons. This capability enables the rig to exert significant downward force during drilling operations, which is essential for penetrating hard rock formations and achieving deep boreholes with minimal effort. The high axial pressure ensures that drilling is both fast and effective, reducing downtime and increasing overall productivity on site.
The drill pipe length is a critical factor in drilling operations, and this Reverse Circulation Drilling Rig is equipped with drill pipes measuring 3 meters in length. This length strikes a perfect balance between reach and operational convenience, allowing for effective drilling while simplifying pipe handling and assembly. The 3-meter drill pipes are designed for durability and reliability, ensuring consistent performance even under the most challenging conditions.
Speed is a crucial element in drilling efficiency, and this Geological Drilling Rig Machine excels with its fast lifting speed of 29 meters per minute. This rapid lifting capacity significantly reduces the time required to raise and lower the drill string, thereby accelerating the overall drilling process. Fast lifting speeds contribute to shorter cycle times and increased drilling depth achievements within a given timeframe, making this rig an invaluable asset for geological surveys and mineral exploration projects.
In addition to its fast lifting speed, the rig boasts a substantial lifting force of 29 tons. This powerful lifting capability ensures that the rig can handle heavy drill strings and casing pipes with ease, providing stability and safety during operations. The combination of high lifting force and fast lifting speed enhances the rig's operational efficiency, allowing it to manage demanding drilling tasks that require both strength and precision.
The Reverse Circulation Drilling Rig is specifically designed to optimize the reverse circulation drilling method, which is known for its efficiency in sample collection and reduced contamination. This Geological Drilling Rig Machine enables effective segregation of cuttings and fluids, ensuring that geological samples are preserved in their original state for accurate analysis. This feature makes the rig particularly valuable in mineral exploration, environmental drilling, and geotechnical investigations.
Durability and reliability are paramount in drilling equipment, and this rig is constructed with high-quality materials and advanced engineering techniques. It is built to withstand harsh environmental conditions and continuous operation, minimizing maintenance requirements and downtime. Operators can rely on this Geological Drilling Rig Machine for consistent performance, safety, and ease of operation across various drilling projects.
In summary, the Reverse Circulation Drilling Rig combines compact dimensions, powerful axial pressure, optimal drill pipe length, rapid lifting speed, and substantial lifting force to deliver a superior Geological Drilling Rig Machine. Its design and capabilities make it an ideal choice for geological exploration and drilling tasks that demand efficiency, precision, and reliability. Whether deployed in remote locations or challenging geological settings, this rig stands out as a dependable solution for achieving successful drilling outcomes.
| Air consumption | 16-75 m³/min |
| Weight | 12.5 T |
| Axial pressure | 7 T |
| Uphill angle | 21° |
| Moving speed | 3.5 Km/h |
| Fast lifting speed | 29 m/min |
| Lifting force | 29 T |
| Max rotary speed | 75/150 R/min |
| Fast feeding speed | 33 m/min |
| Drill pipe length | 3 m |
The Shandong Zhengyuan FSL600 Reverse Circulation Drilling Rig, originating from Shandong Province, is a highly versatile Geological Drilling Rig Machine designed for a wide range of drilling applications. With its compact dimensions of 7*2.1*2.9m and a jacks stroke of 1.7m, this rig is optimized for efficient maneuverability and operation in various working environments. Its drilling diameter capability ranges from 105mm to 450mm, allowing it to handle diverse geological formations with precision and reliability.
This Geological Drilling Rig Machine is ideally suited for mineral exploration, water well drilling, and geotechnical investigations. The reverse circulation technology employed in the FSL600 model ensures efficient cuttings removal and sample collection, making it indispensable for accurate subsurface analysis. The drill pipe length of 3m facilitates deep drilling operations, while the maximum rotary torque of 12000/6000Nm provides powerful drilling performance, enabling the rig to penetrate tough rock layers and complex geological strata.
In addition to mineral exploration, the FSL600 is widely used in construction projects requiring geological surveys and foundation assessments. Its robust design and advanced drilling capabilities make it a preferred choice for engineers and geologists conducting site investigations for tunnels, dams, and large infrastructure developments. The rig’s ease of transport and setup further enhances its suitability for remote and challenging drilling sites.
Furthermore, the Shandong Zhengyuan Geological Drilling Rig Machine supports environmental drilling programs where precise sampling and minimal site disturbance are critical. Its reverse circulation system minimizes contamination risks while delivering high-quality samples for environmental assessments and monitoring projects. Overall, the FSL600 model represents a cutting-edge solution for a broad spectrum of drilling occasions and scenarios, combining advanced technology with reliable performance to meet the demands of modern geological exploration and engineering applications.
Shandong Zhengyuan offers customized solutions for the FSL600 Reverse Circulation Drilling Rig, designed specifically to meet your geological exploration needs. As a leading Geological Drilling Rig Machine manufacturer, we provide tailored options to optimize performance for your projects.
The FSL600 model, originating from Shandong Province, features compact dimensions of 7*2.1*2.9m, ensuring ease of transport and operation in various terrains. With a maximum rotary torque of 12000/6000Nm and a max rotary speed of 75/150 R/min, this Geological Drilling Rig Machine delivers powerful and efficient drilling capabilities.
Our customization services include adjustments to axial pressure up to 7T and drilling depths reaching 600m, allowing the Geological Drilling Rig Machine to be perfectly adapted to your specific geological conditions and project requirements. Trust Shandong Zhengyuan to provide a reliable and high-performance drilling solution tailored just for you.
Our Reverse Circulation Drilling Rig is supported by a dedicated technical support team specializing in drilling equipment. We offer comprehensive services including installation guidance, routine maintenance, troubleshooting, and repair assistance to ensure optimal performance and longevity of your rig.
Our experts provide detailed operational training tailored to your team’s needs, enhancing safety and efficiency during drilling operations. Additionally, we supply genuine replacement parts and consumables to maintain the highest standards of reliability and durability.
For ongoing projects, we offer on-site technical support to minimize downtime and address any issues promptly. Our commitment is to deliver timely solutions and expert advice, helping you achieve precise drilling results with maximum productivity.
We also provide customized service plans and remote diagnostics to proactively monitor equipment health and prevent unexpected failures. Trust our professional support services to keep your Reverse Circulation Drilling Rig running smoothly in all conditions.
